Roller Lever Valve R-5-1/4-B 8996 German Original Mechanical Control Valve
Roller Lever Valve R-5-1/4-B 8996 German Original Mechanical Control Valve

  • R-5-1/4-B

  • FESTO

  • 8996

库存： 0
Inquire
Add to Basket

R-5-1/4-B

8996


Technical Data

  • Valve function5/2-way, monostable

  • Type of actuationMechanical

  • Standard nominal flow rate (standardised to DIN 1343)550 l/min

  • pneumatic working portG1/4

  • Operating pressure-0.095 MPa ... 1 MPa

  • Operating pressure-0.95 bar ... 10 bar

  • DesignPoppet seat

  • Nominal size7 mm

  • Type of pilotingDirect

  • Symbol00991361

  • LABS (PWIS) conformityVDMA24364-B1/B2-L

  • Ambient temperature-10 °C ... 60 °C

  • Actuating force75 N

  • Product weight340 g

  • Type of mountingWith through-hole

  • Pneumatic connection, port 1G1/4

  • Pneumatic connection, port 2G1/4

  • Pneumatic connection, port 3G1/4

  • Pneumatic connection, port 4G1/4

  • Pneumatic connection, port 5G1/4

  • Material sealsNBR

  • Material housingDie-cast aluminium
