Vacuum Pump Vad-1/8 14015, Original From Germany

VAD-1/8

14015

Technical Data

• Nominal size, Laval nozzle0.8 mm

• Mounting positionoptional

• Ejector characteristicHigh vacuum

• DesignT-shape

• Symbol00991482

• Operating pressure0.15 MPa ... 1 MPa

• Operating pressure1.5 bar ... 10 bar

• Operating pressure21.75 psi ... 145 psi

• Max. vacuum80 %

• Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]

• Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)

• LABS (PWIS) conformityVDMA24364-B1/B2-L

• Media temperature-20 °C ... 80 °C

• Ambient temperature-20 °C ... 80 °C

• Type of mountingWith through-hole

• Pneumatic connection, port 1G1/8

• Pneumatic connection, port 3G1/8

• Vacuum connectionG1/8

• Material housingDie-cast aluminium
